Main technical parameters:
Power voltage | 220V/50HZ | 380V/50HZ |
Installation requirements | 220V Power voltage, air source, 10kg heat transfer oil | 380V Power voltage, air source, 35kg heat transfer oil |
PLC | XINJIE | XINJIE |
Touch screen | XINJIE Touchwin | XINJIE Touchwin |
Stirring speed | 0~90 rpm | 0~90 rpm |
Filling machine power | 2.2KW | 5.5KW |
Filling barrel volume | 20L | 70L |
Production capacity: Production capacity | 20-70pcs/min (Related to filling volume and formulation) | 20-70pcs/min (Related to filling volume and formulation) |
Overall size | 800mm*820mm*1600mm | 1000mm*950mm*1600mm |
Usage and function:
1. The gear pump filling machine is suitable for the quantitative filling of all kinds of liquid (paste) products, such as: cooling oil, Wanjing oil, foundation cream, hair wax, disc lipstick, lip balm and other packaging products.
2. The double-layer heating of the material bucket can ensure uniform heating of raw materials. The pump and filling nozzle are independently heated, without dead heat.
3. Through the gear pump motor piston type quantitative filling, the filling is more stable and fast, and the low noise makes the production environment more comfortable.
4. The material bucket is equipped with lifting and PLC program control, which makes the operation simpler and easier for employees to learn.
